Instruments and controls/Meters and gauges
while the ignition switch is in the
“LOCK”/“OFF” or “ACC” position, the
fuel gauge will light up and indicate the
amount of fuel remaining in the tank.
The indicators will turn off when:
– The TRIP RESET switch is not
operated for approximately 10 sec-
onds.
– The driver’s door is opened and
then closed.
& ECO gauge (if equipped)
If the ECO gauge moves towards the +
side, this indicates better fuel efficiency.
NOTE
. The ECO gauge shows only an
approximate indication of fuel effi-
ciency.
. After resetting the trip meter, the
average rate of fuel consumption is not
shown until you have driven for 1 mile
(or 1 km). Before that time, the ECO
gauge does not operate.
& Combination meter settings
Meter and vehicle settings can be set on
the combination meter.
1)
2)
Type A combination meter
Type B combination meter
The ECO gauge shows the difference
between the current rate of fuel consump-
tion and the average rate of fuel consump-
tion since the trip meter was last reset.
! Type A combination meter
Various adjustments can be made, such
as switching units shown on the combina-
tion meter and adjusting the warning tone
volume.
While the ignition switch is in the “OFF”
position, each press of TRIP RESET
switch results in items shown in the table
below being switched.
Item
Combination
meter display
3-11
Possible
settings
A trip —
B trip —
Gauge
needle
sweep
function On/Off
Changing
the unit* mile/km
Warning
volume* Lv. 1/Lv. 2/Lv. 3
*: if available
NOTE
. If you switch the units on the
combination meter, the units on the
multi-function display (black and white)
also switches accordingly.
. If either of the following conditions
is met, the combination meter setting
mode will be canceled.
– The driver’s door is opened.
– The TRIP RESET switch is not
operated for approximately 10 sec-
onds or more.
– CONTINUED –
