8-16
Driving tips/Trailer hitch (Crosstrek models — dealer option)
! Removal and installation of the
crossbars
Trailer hitch (Crosstrek models — dealer option)
WARNING
Each of the two roof moldings has two
mounting points for crossbars. Each
mounting point is fitted with a cover. Use
a screwdriver to remove the covers. When
installing the crossbars on the roof molding, follow the manufacturer’s instructions.
. Never exceed the maximum
weight specified for the trailer
hitch. Exceeding the maximum
weight could cause an accident
resulting in serious personal injuries. Permissible trailer weight
changes depending on the situation. For possible recommendations and limitations, refer to
“Trailer towing (Crosstrek models)” F8-18.
. Trailer brakes are required when
the towing load exceeds 1,000
lbs (453 kg). Be sure your trailer
has safety chains and that each
chain will hold the trailer’s maximum gross weight. Towing trailers without safety chains could
create a traffic safety hazard if
the trailer separates from the
hitch due to coupling damage or
hitch ball damage.
. Be sure to check the hitch pin
and safety pin for positive locking placement before towing a
trailer. If the ball mount comes off
.
.
.
.
the hitch receiver, the trailer
could get loose and create a
traffic safety hazard.
Although towing regulations for
trailer or caravan vehicles vary
by state/region, all regulations
agree that specifications such
as the maximum gross trailer
weight must not exceed the lesser of the following:
– Maximum gross trailer weight
– Maximum gross tongue
weight
– GVWR
– GAWR
Failure to comply with the procedures set forth will not only
compromise your safety, but will
also negate your insurance coverage and/or may violate the
state road and traffic acts and
regulations.
Use only the ball mount supplied
with this hitch. Use the hitch only
as a weight carrying hitch. Do not
use with any type of weight
distributing hitch.
The standard bumper beam must
be installed after you remove the
trailer hitch. Consult a SUBARU
