3-10
Instruments and controls/Meters and gauges
The display can be switched as shown in
the following sequence by pressing the
trip knob.
! Type B combination meter
Perform the procedures described in
“Gauge Initial Movement” F3-41.
& Speedometer
The speedometer shows the vehicle
speed.
& Odometer
*: They cannot be displayed when the
ignition switch is in the “ON” position.
To change the current setting, press the
trip knob for at least 2 seconds.
Type B
1) Trip knob (U.S.-spec. models)
2) Trip knob (except U.S.-spec. models)
: Activated
: Deactivated
This meter displays the odometer when
the ignition switch is in the “ON” position.
The odometer shows the total distance
that the vehicle has been driven.
NOTE
. Your vehicle’s initial movement
setting of the meter/gauge needles
has been set for activation “ ” at
the time of shipment from the factory.
. It is not possible to change the initial
movement setting of the meter/gauge
needles when the ignition switch is in
the “ON” position. Change the setting
when the ignition switch is in the
“LOCK”/“OFF” or “ACC” position.
Type A
1) Trip knob
If you press the trip knob when the ignition
switch is in the “LOCK”/“OFF” or “ACC”
position, the odometer/trip meter will light
up. If you do not press the trip knob within
10 seconds of illumination of the odometer/trip meter, the odometer/trip meter
will turn off.
Also, if you open and close the driver’s
door within 10 seconds of illumination of
the odometer/trip meter, the odometer/trip
meter will turn off.
