Maintenance and service/Replacing bulbs
1)
2)
3)
4)
Rear side marker light
Rear turn signal light
Backup light
Stop light/Tail light
3. Remove the bulb socket from the rear
combination light assembly by turning it
counterclockwise.
4. Pull the bulb out of the bulb socket and
replace it with a new one.
5. Set the bulb socket into the rear
combination light assembly and turn it
clockwise until it locks.
1)
2)
3)
Guide pins
Catch
Clip
11-41
7. Tighten the upper and lower screws.
6. Put the rear combination light assembly into place while aligning the 2 guide
pins and a catch with the guide holes and
a clip on the vehicle.
– CONTINUED –
