1-34
Seat, seatbelt and SRS airbags
installing a child restraint system only on
the rear seat window-side seating positions. For each window-side seating position, two lower anchorages are provided.
Each lower anchorage is located where
the seat cushion meets the seatback.
system, be sure to confirm that the
seatback is securely locked into
place. Otherwise, in an accident,
serious injury or death could result.
1. Shake the seatback slightly to confirm
that it is securely locked into place.
– For 5-door models, it is possible to
check whether the seatback is locked
visually. If the seatback is locked into
place, the red colored unlocking marker which is attached to the bottom of
the lock release knob is invisible. For
details, refer to “5-door models” F111.
*: If equipped
The tether anchorages (upper anchorages) are provided at the locations
shown in the above illustration. For details, refer to “Top tether anchorages” F135.
To install a child restraint system using
lower and tether anchorages, perform the
following procedure.
WARNING
Before installing a child restraint
2. You will find marks “ ” at the bottom of
the rear seat seatbacks. These marks
indicate the positions of the lower an-
chorages (bars).
Remove the covers and locate the lower
anchorages (bars).
3. Remove the rear seat head restraint.
For details, refer to “Rear windows side
seating position” F1-8.
