Seat, seatbelt and SRS airbags
seatbelt restrains the front seat occupant
more effectively.
When a seatbelt pretensioner is activated,
an operating noise will be heard and a
small amount of smoke will be released.
These occurrences are normal and not
harmful. This smoke does not indicate a
fire in the vehicle.
Once the seatbelt pretensioner has been
activated, the seatbelt pretensioner remains locked. Consequently, the seatbelt
cannot be pulled out and retracted and
therefore must be replaced.
NOTE
. Seatbelt pretensioners are not designed to activate in minor frontal
impacts, in side impacts or in rear
impacts.
. When a rollover accident occurs, the
lap belt pretensioner does not activate;
however, as the curtain airbags deploy,
the shoulder belt pretensioner is activated. At this time, the driver’s side
seatbelt pretensioner and passenger’s
side shoulder belt pretensioner activate simultaneously.
. The following four components operate simultaneously.
– Seatbelt pretensioner for driver
– Seatbelt pretensioners for front
passenger
– SRS frontal airbag for driver
– SRS frontal airbag for front passenger*
*: This does not operate if the occupant
detection system deactivates airbag operation. For details, refer to “Front
passenger’s SRS frontal airbag” F1-44.
. Pretensioners are designed to function on a one-time-only basis. In the
event that a pretensioner is activated,
both the driver’s and front passenger’s
seatbelt retractor assemblies should
be replaced only by an authorized
SUBARU dealer. When replacing seatbelt retractor assemblies, use only
genuine SUBARU parts.
. If either front seatbelt does not
retract or cannot be pulled out due to
a malfunction or activation of the
pretensioner, contact your SUBARU
dealer as soon as possible.
. If the front seatbelt retractor assembly or surrounding area has been
damaged, contact your SUBARU dealer
as soon as possible.
. When you sell your vehicle, we urge
you to explain to the buyer that it has
seatbelt pretensioners by alerting the
buyer to the contents of this section.
1-23
WARNING
. To obtain maximum protection,
the occupants should sit in an
upright position with their seatbelts properly fastened. Refer to
“Seatbelts” F1-12.
. Do not modify, remove or strike
the front seatbelt retractor assemblies or surrounding area.
This could result in accidental
activation of the seatbelt pretensioners or could make the system inoperative, possibly resulting in serious injury. Seatbelt
pretensioners have no user-serviceable parts. For required servicing of front seatbelt retractors
equipped with seatbelt pretensioners, consult your SUBARU
dealer.
. When discarding front seatbelt
retractor assemblies or scrapping the entire vehicle due to
collision damage or for other
reasons, consult your SUBARU
dealer.
– CONTINUED
