6-12
Interior equipment
2. Stow the cover housing in the cargo
area end.
& To install the cover housing
3. Put the cargo floor board back while
hanging two retaining straps on the hooks
that are located on the rear wall of cargo
area.
2. Insert both ends of the cover housing
into the recesses of the retainers.
1. Shorten the cover housing.
Cargo tie-down hooks
(5-door – if equipped)
The cargo area is equipped with four tiedown hooks so that cargo can be secured
with a cargo net or ropes.
When using the front tie-down hooks, turn
them down out of the storing recesses.
CAUTION
The cargo tie-down hooks are designed only for securing light cargo.
Never try to secure cargo that
exceeds the capacity of the hooks.
The maximum load capacity is 22
lbs (10 kg) per hook.
