3-14
Instruments and controls
& Charge warning light
If this light illuminates when the engine is
running, it may indicate that the charging
system is not working properly.
If the light illuminates while driving or does
not turn off after the engine starts, stop the
engine at the first safe opportunity and
check the alternator belt. If the belt is
loose, broken or if the belt is in good
condition but the light remains illuminated,
contact your nearest SUBARU dealer
immediately.
& Oil pressure warning
light
If this light illuminates when the engine is
running, it may indicate that the engine oil
pressure is low and the lubricating system
is not working properly.
If the light illuminates while driving or does
not turn off after the engine starts, stop the
engine at the first safe opportunity and
check the engine oil level. If the oil level is
low, add oil immediately. If the engine oil is
at the proper level but the light remains
illuminated, contact your nearest
SUBARU dealer immediately.
For details about checking the engine oil
level or adding the engine oil, refer to
“Engine oil” F11-7.
CAUTION
Do not operate the engine with the
oil pressure warning light illuminated. This may cause serious engine damage.
& Engine low oil level
warning light
This light illuminates when the engine oil
level decreases to the lower limit. The
illuminating conditions and remaining oil
quantity are as follows.
. when the ignition switch is in the “ON”
position but the engine is not running:
approximately 2.4 US qt (2.3 liters, 2.0
Imp qt)
. while the engine is running: approximately 4.0 US qt (3.8 liters, 3.3 Imp qt)
If the engine low oil level warning light
illuminates while driving, park the vehicle
in a safe and level location, and then
check the engine oil level. When the
engine oil level is not within the normal
range, refill with engine oil. Refer to
“Engine oil” F11-7.
If the warning light does not turn off after
refilling the engine oil, or the warning light
illuminates even though the engine oil
level is within the normal range, have the
vehicle checked by a SUBARU dealer.
NOTE
. The engine low oil level warning
light will not turn off immediately even
if you replace or add engine oil. It will
turn off after the vehicle starts to move.
Depending on the driving conditions
and environment where the vehicle is
driven, it may take a period of approximately 10 minutes for the warning light
to turn off. If the warning light has still
not turned off after 15 minutes have
elapsed, contact your SUBARU dealer.
. The warning light may illuminate
temporarily in the following conditions
because a low oil level may be detected
as a result of significant oil movement
in the engine.
– when the vehicle is considerably
inclined on an uphill or steep slope
– when the vehicle has continuously accelerated and decelerated
– when the vehicle is continuously
turned
– when the vehicle is driven on a
road that alternates continuously
between uphill and downhill
