4-8
Climate control
Automatic climate control
system (if equipped)
Although this climate control system can
be used as a full-automatic climate control
system, it can also, if desired, be used as
a semi-automatic climate control system.
When it is used as a full-automatic climate
control system, the outlet air temperature,
fan speed, airflow distribution, air inlet
control, and air conditioner compressor
operation are all automatically controlled
to maintain a constant, comfortable temperature inside the vehicle.
sor automatically and the “A/C” indicator light on the air conditioner button
illuminates.
& Control panel
Place the temperature control dial in the
position for your desired temperature, then
set the other dials and buttons as described in the following. The system’s
functions will then switch to AUTO mode
and be controlled automatically.
. Airflow control dial: AUTO position
. Fan speed control dial: AUTO position
& To use as semi-automatic
climate control system
NOTE
. Operate the automatic climate control system when the engine is running.
. When the engine coolant is cold, the
blower does not run.
. In the “AUTO” mode, when the air
temperature in the passenger compartment is sufficiently cool, the air conditioner compressor does not operate.
For efficient defogging or dehumidifying in cold weather, press the “A/C”
button to operate the air conditioner
compressor.
. Even when cooling is not necessary,
setting the temperature much lower
than the current outlet air temperature
turns on the air conditioner compres-
& To use as full-automatic climate control system
1)
2)
3)
4)
5)
6)
Temperature control dial
Fan speed control dial
Airflow control dial
Control switch of the defogger and deicer
system (Refer to “Defogger and deicer”
F3-49.)
Air inlet selection button
Air conditioner button
Each function can be individually set to
AUTO mode independently of the others.
Any function set to AUTO mode is controlled automatically. Any function not set
to AUTO mode can be manually adjusted
as desired.
The temperature can be set within a range
of 65 to 858F (20 to 308C).
