7-34
Starting and operating
position and turns off after approximately 2
seconds.
This is an indication that the ABS system
is working properly.
When driving with an insufficient battery
voltage such as when the engine is jump
started, the ABS warning light may illuminate. This is due to the low battery voltage
and does not indicate a malfunction.
When the battery becomes fully charged,
the light will turn off.
CAUTION
If the warning light behaves as
described below, the ABS system
may not be working properly.
When the warning light is on, the
ABS function shuts down; however,
the conventional brake system continues to operate normally.
. The warning light does not illuminate when the ignition switch
is turned to the “ON” position.
. The warning light illuminates
when the ignition switch is
turned to the “ON” position, but
it does not turn off even when the
vehicle speed exceeds approximately 8 mph (12 km/h).
. The warning light illuminates dur-
ing driving.
If these occur, have the ABS system
repaired at the first available opportunity by your SUBARU dealer.
NOTE
If the warning light behavior is as
described below, the ABS system may
be considered normal.
. The warning light illuminates just
after the engine is started but turns off
immediately and remains off.
. The warning light remains illuminated after the engine has been started,
but it turns off
