Instruments and controls
F7-19.
! Driver’s control center differential auto [−] indicator
light
When the AUTO
AUTO [−] indicator
For details, refer
Center Differential
F7-19.
[−] mode is set, the
light illuminates.
to “Driver’s Control
(DCCD) (WRX STI)”
When you select the manual mode of the
driver’s control center differential, the
initial limited slip differential (LSD) torque
that is currently selected for the center
differential is indicated by the illumination
of these indicator lights.
! Warning light
& Driver’s control center differential indicator and warning
lights (WRX STI)
! Indicator lights
All the indicator lights will flash in the event
that the driver’s control center differential
has a malfunction. Have the vehicle
inspected by your SUBARU dealer. For
details, refer to “Driver’s Control Center
Differential (DCCD) (WRX STI)” F7-19.
When the ignition switch is turned to the
“ON” position, all the indicator lights
illuminate for 2 seconds, and then turn off.
3-31
& REV indicator light
(WRX STI)
When the ignition switch is turned to the
“ON” position, the indicator light illuminates for 2 seconds, and then turns off.
This light illuminates when the engine
speed reaches a level set by driver or
when the tachometer needle enters the
red zone.
