Subaru Forester Manuals Pioneer® Audio/Navigation System Manual (U310BT) | Page 21

Chapter How to use the navigation menu screens Operating menu screens (e.g. “Navigation Menu” screen) 04 Operating the on-screen keyboard 1 1 6 3 3 1 Screen title 2 Shows the next or previous page. 3 Returns the previous screen. Operating list screens (e.g. city list) 1 4 5 2 5 4 1 Text box Displays the characters that are entered. If there is no text in the box, an informative guide with text appears. 2 Keyboard Touch the keys to enter the characters. 3 Returns the previous screen. 4 [0-9], [Sym.], [Others]: You can enter other characters of alphabet. You can also enter text with marks such as [&] or [+] or numbers. Touch to toggle the selection. How to use the navigation menu screens 2 2 p When you use any of “A”, “Ä”, “Å”, “Æ”, the displayed result is the same. 3 1 Screen title 2 Touching or on the scroll bar scrolls through the list and allows you to view the remaining items. 3 Returns the previous screen. 4 Listed items Touching an item on the list allows you to narrow down the options and proceed to the next operation. 5 If all of characters cannot be displayed within the displayed area, touching the key to the right of the item allows you to see remaining characters. 5 [OK]: Confirms the entry and allows you to proceed to the next step. 6 : Deletes the input text one letter at a time, beginning at the end of the text. Continuing to touch the button deletes all of the text. En 21
