Messages for audio functions
When problems occur in the audio source, a message may appears on the display. Refer to the
table below to identify the problem, then take the suggested corrective action. If the error persists,
contact your dealer or your nearest Pioneer Service Center.
Built-in CD drive
Cause
Dirty
Action (Reference)
Clean the disc.
Scratched disc
Replace the disc.
Error10, 11, 12, 15, 17, 30, A0,
CHK CDCORE
Electrical or mechanical
Turn the ignition switch OFF and back ON, or
switch to a different source, then back to the
CD player.
Error-15
The inserted disc does not contain
any data.
Replace the disc.
Error-23
The CD format cannot be played
back.
Replace the disc.
Error-22
The inserted disc does not contain
any files that can be played back.
Replace the disc.
No Audio
The inserted disc does not contain
any files that can be played back.
Replace the disc.
TRK Skipped
The inserted disc contains files that Replace the disc.
are protected by DRM.
Protect
All the files on the inserted disc are
secured by DRM.
Replace the disc.
Heat
The temperature of the navigation
system is outside of the normal operating range.
Wait until the unit’s temperature returns to
within normal operating limits.
Appendix
Message
Error-11, 12, 17, 30
USB/iPod
Message
Cause
Action (Reference)
No Audio
The connected USB storage device
does not contain any files that can
be played back.
Store playable files.
Protect
All the files on the inserted external Store playable files.
storage device are secured by DRM.
TRK Skipped
The protected files are skipped.
Check USB
The USB connector or USB cable is Confirm that the USB connector or USB
short-circuited.
cable is not caught in something or damaged.
Store playable files.
The connected USB storage device Disconnect the USB storage device and do
consumes more than 500 mA (maxi- not use it. Turn the ignition switch to OFF,
then to ACC or ON and then connect the
mum allowable current).
compliant USB storage device.
Error-A1
The connected USB storage device Disconnect the USB storage device and do
consumes more than 500 mA (maxi- not use it. Turn the ignition switch to OFF,
then to ACC or ON and then connect the
mum allowable current).
compliant USB storage device.
