Chapter
Before you start
02
Ejecting a disc
8 BAND/ESC button
This button is used only for the audio function.
= For more details, refer to the descriptions
from Chapter 13 to Chapter 27.
Inserting and ejecting an
SD memory card
9 Detachable device
a LCD screen
b RESET button
= For details, refer to Resetting the microprocessor on page 8.
c Bluetooth connection status indicator
Lights up when your phone is paired to the
navigation system by Bluetooth wireless
technology.
d DETACH button
Press to remove the detachable device from
the head unit.
Inserting and ejecting a disc
Inserting a disc
% Insert a disc into the disc loading slot.
% Press the EJECT button.
The disc is ejected.
CAUTION
! Keep the dummy SD card out of the reach of
small children to prevent them from accidentally swallowing it.
! To prevent data loss and damage to the storage device, never remove it from this navigation system while data is being transferred.
! If data loss or corruption occurs on the storage device for any reason, it is usually not
possible to recover the data. Pioneer accepts
no liability for damages, costs or expenses
arising from data loss or corruption.
Before you start
7 SRC/OFF button
This button is used only for the audio function.
= For more details, refer to the descriptions
from Chapter 13 to Chapter 27.
Inserting an SD memory card
1 Remove the detachable device from
the head unit.
= For details, refer to Removing and attaching
the detachable device on page 15.
2 Insert an SD memory card into the SD
card slot.
Insert it with the contact the top of the detachable device and press the card until it clicks
and completely locks.
Label side
p Do not insert anything other than a disc
into the disc loading slot.
En
11
