STARTING AND OPERATING 409
BSD / RCTA APPROACH INDI- CATOR LIGHT / WARNING BUZ- ZER s07bm03
While the BSD / RCTA is active, the following item( s) will operate to alert the driver:
. The BSD / RCTA approach indicator light( when there are vehicles in the neighboring lanes).
. The BSD / RCTA approach indicator light and warning buzzer( when a vehicle is approaching from the left or right side while your vehicle is reversing)
BSD / RCTA approach indicator light s07bm0301
BSD / RCTA approach indicator light on the outside mirrors
S _ 703175-W
The indicator light will illuminate when a vehicle approaching from behind is detected.
The indicator light will flash to warn the driver of dangers under the following conditions.
. While the indicator light is illuminating, if the turn signal lever is operated toward the side in which this light turned on
. When reversing the vehicle while the system detects a vehicle approaching from either side
Vehicle detected in adjacent lane indicator( models with 12.3-inch meter display)
S _ 703462-W
When a vehicle is detected( white area with yellow outline is indicated)
When the turn signal lever is being operated while a vehicle is detected( yellow area is indicated)
Your vehicle indicator * 1
When your vehicle indicator * 1 is displayed, the combination meter also shows the vehicle detection status of the adjacent lane.
* 1: For details regarding your vehicle indicator, refer to the Owner’ s Manual supplement for the EyeSight system.
NOTE
. When your vehicle indicator is turned off or your vehicle is reversing, the combination meter will not display the vehicle detected in adjacent lane indicator.
. When the EyeSight system is malfunctioning or is not functioning temporarily, the vehicle detected in adjacent lane indicator is displayed even if your vehicle indicator is not shown.
BSD / RCTA approach indicator light dimming function:
When the headlights are turned on, the brightness of the BSD / RCTA approach indicator light will be reduced.
NOTE
. You may have difficulty seeing the BSD / RCTA approach indicator light under the following conditions.
7
– CONTINUED –
