STARTING AND OPERATING 375 driver’ s side.
Even when the vehicle is driven a very short distance, the tires get warm and their pressures increase accordingly. Be sure to let the tires cool thoroughly before adjusting their pressures to the standard values shown on the tire inflation pressure label. Refer to“ Tires and Wheels” FP522. The tire pressure monitoring system does not function when the vehicle is stationary. After adjusting the tire pressures, increase the vehicle speed to at least 25 mph( 40 km / h) to start the TPMS rechecking of the tire inflation pressures. If the tire pressures are now above the severe low pressure threshold, the low tire pressure warning light should turn off a few minutes later.
If this light still illuminates while driving after adjusting the tire pressure, a tire may have significant damage and a fast leak that causes the tire to lose air rapidly. If you have a flat tire, refer to“ Flat Tires” FP474.
. When a replacement tire is mounted or a wheel rim is replaced without the original pressure sensor / transmitter being transferred, the low tire pressure warning light will illuminate steadily after blinking for approximately one minute. This indicates the TPMS is unable to monitor all four road wheels. Contact your SUBARU dealer as soon as possible for tire and sensor replacement and / or system resetting.
CAUTION
Do not place metal film or any metal parts under the driver’ s seat. This may cause poor reception of the signals from the tire pressure sensors, and the tire pressure monitoring system will not function properly.
CERTIFICATION FOR TIRE PRESSURE MONITORING SYSTEM
TPMS SCREEN s07ao01
ZOM0993-W
s07ao05
7
S _ 703352-W
This screen displays each tire pressure. Refer to“ Basic Screens” FP212.
