STARTING AND OPERATING 365
7-10. BRAKING BRAKING TIPS s07ak
s07ak01
WARNING
Never rest your foot on the brake pedal while driving. This can cause dangerous overheating of the brakes and needless wear on the brake pads.
When the brakes get wet s07ak0101
When driving in rain or after washing the vehicle, the brakes may get wet. As a result, brake stopping distance will be longer. To dry the brakes, drive the vehicle at a safe speed while lightly depressing the brake pedal to heat up the brakes.
Use of engine braking s07ak0102
Remember to make use of engine braking in addition to foot braking. When descending a grade, if only the foot brake is used, the brakes may start working improperly because of brake fluid overheating, caused by overheated brake pads. To help prevent this, shift into a lower gear to get stronger engine braking.
Braking when a tire is punctured s07ak0103
Do not depress the brake pedal suddenly when a tire is punctured. This could cause a loss of control of the vehicle. Keep driving straight ahead while gradually reducing speed. Then slowly pull off the road to a safe place.
BRAKE SYSTEM s07ak02
Two separate circuits s07ak0201
Your vehicle has a dual circuit brake system. Each circuit works diagonally across the vehicle. If one circuit of the brake system should fail, the other half of the system still works. If one circuit fails, the brake pedal will go down much closer
to the floor than usual and you will need to press it down much harder. And a much longer distance will be needed to stop the vehicle.
Electronic brake booster s07ak0207
The vehicle is equipped with an electronic brake booster to provide additional braking force. Do not turn off the ignition switch while driving because that will turn off the brake booster, resulting in poor braking power.
The brakes will continue to work even when the brake booster completely stops functioning. If this happens, you will have to depress the pedal much harder than during normal braking, and the braking distance will increase.
NOTE
When the following operations are performed, an operating sound from the electronic brake boost control module may be heard. This is not a malfunction.
. The brake pedal was operated.. The driver’ s door was opened.. The EyeSight function was activated.
. Several minutes have passed after the engine stopped.
Supplemental booster function when pressure fails:
If there is a malfunction in the brake system, the power for the braking will be stored by controlling the hydraulic pressure of the Vehicle Dynamics Control system.
When the brake pedal is depressed while the supplemental booster function is operating, an operation sound and brake pedal vibration may be generated.
Brake assist system s07ak0203
WARNING
Do not be overconfident about the brake assist. It is not a system that brings more braking ability to the vehicle beyond its braking capability.
– CONTINUED –
