INSTRUMENTS AND CONTROLS 219
. Radio. Media. Phone. Apps. Add Shortcut Lower main screen:
For details about the setting items, refer to“ Shortcut Icons” FP220.
If this screen changes to the climate control screen, refer to“ Dual 7.0-Inch Display Models” FP288.
HOME BUTTON
Press menu.
( HOME) to display the top s03bw01
STATUS BAR s03bw02
The driver profiles icon, outside temperature and clock are shown on the display.
NOTE
. The outside temperature indicator shows the temperature in the area around the sensor. However, the temperature may not be indicated correctly or the update may be delayed in the following conditions.
– While parking or driving at low
speeds – When the outside temperature
changes suddenly( example: when going in and out of an underground parking area or when passing
through a tunnel) – When starting the engine after
being parked for a certain period of time
. You can set the temperature units to be displayed in Fahrenheit(° F) or Celsius(° C). For details, refer to“ Settings icon( General settings)” FP221.
. The clock can be shown in either 12- hour display or 24-hour display. For details about the setting, refer to“ Setting 12-Hour Display / 24-Hour
Display
” FP247.
. Touch the clock on the status bar to display the clock setting screen. Refer to“ Clock” FP246.
CLIMATE CONTROL SCREEN s03bw03
S _ 307910-W
Driver’ s seat heater icon *
Set temperature indicator( driver’ s side)
SYNC mode indicator Airflow mode Climate control mode Air inlet selection Air conditioner ON indicator Dynamic Ventilation mode indicator
Set temperature indicator( passenger’ s side)
Dynamic Ventilation ON / OFF icon Front passenger’ s seat heater icon * Customizable icon Fan speed control Climate control ON / OFF icon *: If equipped
When operating the climate control system, the main screen switches to the climate control screen. For details about climate control operation, refer to“ Climate Control Panel” FP287.
– CONTINUED –
3
