INSTRUMENTS AND CONTROLS 179
The gauge will turn off when the TRIP RESET switch is not operated for approximately 10 seconds.
ENGINE COOLANT TEMPERA- TURE GAUGE s03ad08 should be avoided.
CAUTION
If the pointer exceeds the normal operating range, safely stop the vehicle as soon as possible.
Refer to“ Engine Overheating” FP481.
3
COMBINATION METER SET- TINGS s03ad16
Meter settings can be set on the center information display. For details, refer to the following sections.
–“ Settings icon( General settings)” FP221( dual 7.0-inch display models)
–“ Settings icon( General settings)” FP238( 11.6-inch display models)
S _ 308058-W
4.2-inch combination meter display 12.3-inch combination meter display Normal operating range
The temperature gauge shows engine coolant temperature when the ignition switch is in the“ ON” position.
The coolant temperature will vary in accordance with the outside temperature and driving conditions.
We recommend that you drive moderately until the pointer of the temperature gauge reaches near the middle of the range. Engine operation is optimum with the engine coolant at this temperature range and high revving operation when the engine is not warmed up enough
