INSTRUMENTS AND CONTROLS 255
2. Position the hand-held remote( garage door opener remote) 1 to 3 inches( 2 to 8 cm) away from the HomeLink ® button that you would like to program.
NOTE
Some devices may require you to replace this“ Programming a New HomeLink ® button” step 3 with procedures noted in the“ Gate Operator / Canadian Programming” section. Refer to“ Gate Operator / Canadian Programming” FP256.
4. Press the HomeLink ® button that you would like to program and observe the indicator light.
3
S _ 307929-W
Garage door opener remote
NOTE
Some hand-held remotes( garage door opener remotes) may actually train better at a distance of 6 to 12 inches( 15 to 30 cm). Keep this in mind if you have difficulty with the programming process.
3. While the HomeLink ® indicator light is flashing orange, press and hold the hand-held remote button. Continue pressing the hand-held remote button until the HomeLink ® indicator light changes from orange to green. You may now release the hand-held remote button.
Indicator Light
S _ 307930-W
. If the indicator light remains constant green, your device should operate when the HomeLink ® button is pressed. At this point, if your device operates, programming is complete.
. If the indicator light rapidly flashes green, firmly press, hold for two seconds and release the HomeLink ® button up to three times to complete the programming process. At this point if your device operates, programming is complete. If the device does not operate, continue with the next step of the programming instructions.
S _ 307665-W
– CONTINUED –
