390
STARTING AND OPERATING
surroundings with your eyes when reversing the vehicle.
Example 2
S _ 703288-MW
The detection range of the radar sensors
Vehicle that may be detected
NOTE
The system may detect that a vehicle( C) is passing in front of your vehicle. Always be sure to check the surroundings with your eyes when reversing the vehicle.
OPERATING CONDITIONS s07bm10
The BSD / RCTA will operate when all of the following conditions are met.
. The ignition switch is in the“ ON” position.
. The BSD / RCTA warning indicator and BSD / RCTA OFF indicator are turned off.
. The vehicle is driven at speeds above 7 mph( 12 km / h)( except when reversing).
. The select lever is in the“ R” position( RCTA only).
The BSD / RCTA will not operate in the following situations.
. The BSD / RCTA OFF indicator appears.
. The vehicle speed is below 6 mph( 10 km / h) even when the BSD / RCTA OFF indicator does not appear( except when reversing). NOTE
. In the following cases, the BSD / RCTA will stop operating and the BSD / RCTA warning indicator will appear.
– When a malfunction occurs in the system, including the BSD / RCTA approach indicator light
. If the BSD / RCTA warning indicator appears, exercise proper caution. For details, refer to“ BSD / RCTA Warning Indicator” FP394.
. In the following cases, the BSD / RCTA will temporarily stop operating( or may stop operating) and the BSD / RCTA OFF indicator will appear.
– When the radar sensor becomes significantly misaligned( If the orientation of the radar sensor is shifted for any reason, readjustment is required. Have the sensor
adjusted at a SUBARU dealer.) – When a large amount of snow or
ice sticks to the rear bumper surface around the radar sensors – When the vehicle is driven on a
snow-covered road or in an environment in which there are no objects around( such as in a desert) for a prolonged period of
time – When the temperature around the
radar sensors increases excessively due to long driving on uphill
grades in the summer, etc. – When the temperature around the
radar sensors becomes extremely
low – When the vehicle battery voltage
lowers – When the vehicle voltage exceeds
the battery voltage rating The BSD / RCTA will resume operation once these conditions are corrected, and the BSD / RCTA OFF indicator will disappear. However, if the BSD / RCTA OFF indicator appears for a prolonged period of time, have the system inspected at a SUBARU dealer as soon as possible.
