STARTING AND OPERATING 355
ABS SELF-CHECK s07al01
You may feel a slight shock in the brake pedal and hear the operating noise of the ABS from the engine compartment just after the vehicle is started. This is caused by an automatic functional test of the ABS being carried out and does not indicate any abnormal condition.
ABS WARNING LIGHT s07al02
Refer to“ ABS Warning Light” FP182.
7-12. ELECTRONIC BRAKE FORCE DISTRIBUTION( EBD) SYSTEM s07am
The EBD system maximizes the effectiveness of the brakes by allowing the rear brakes to supply a greater proportion of the braking force. It functions by adjusting the distribution of braking force to the rear wheels in accordance with the vehicle’ s loading condition and speed.
The EBD system is an integral part of the ABS and uses some of the ABS components to perform its function of optimizing the distribution of braking force. If any of the ABS components used by the EBD function fails, the EBD system also stops working.
When the EBD system is operating, you may hear a chattering noise or feel a slight vibration in the brake pedal. This is normal and does not indicate a malfunction.
EBD SYSTEM MALFUNCTIONS s07am01
7
S _ 703143-W
If a malfunction occurs in the EBD system, the system stops working and the following warning lights illuminate simultaneously.
. Brake system warning light. ABS warning light
. Vehicle Dynamics Control warning light
– CONTINUED –
