INTERIOR EQUIPMENT 309
charger switches to the quick-charging mode.
2. When charging is complete, the quickcharging mode ends. To restart quickcharging, switch to the quick-charging mode again.
S _ 602666-W
4. The indicator light illuminates in green when charging is complete.
NOTE
. If the indicator light does not illuminate in orange and device charging does not occur, move the device to the center of the charging area. Depending on the mobile device, the charging coil may not be in the center of the device. In such cases, place the mobile device so that its charging coil is in the center of the charging area.
. The power status of the wireless charger is stored even when the ignition switch is turned to the“ OFF” position.
How to use the quick charge s06bh0101
The following types of mobile devices support quick charging as opposed to normal charging( 5 W).
. Mobile devices compliant with WPC * Ver. 1.2.4 and compatible with fast chargers can be charged up to 10 W.
. iPhone 8( or later) with an iOS version compliant with WPC * Ver. 1.2.4 and compatible with 7.5 W charging.
* WPC: Wireless Power Consortium
1. Press the power switch three times to change to the quick-charging mode while your mobile device is charging in normal mode. The indicator light will change from orange to alternating green and orange when the wireless
To turn off the wireless charger s06bh0104
Press the power switch once. When the wireless charger is OFF, the indicator light turns off.
Indicator light patterns
Indicator light Off
Green( illuminated)
Orange( illuminated)
Green and orange illuminate alternately
Interpretation s06bh0102
The wireless charger is turned off
Standby( ready for charging)* 1 Charging is complete * 2
A mobile device is in the charging area( a mobile device is being detected)
Charging
Quick charging is in progress
* 1: No power is output for charging when the wireless charger is in standby mode. Even if metal objects are placed on the charging tray in this state, they will not overheat.
* 2: For some mobile devices, the indicator light remains orange even after charging is complete.
6
– CONTINUED –
