INSTRUMENTS AND CONTROLS 179
For details about the components monitored by the warning light, refer to“ SRS Airbag System Monitors” FP109.
FRONT PASSENGER’ S FRON- TAL AIRBAG ON AND OFF IN- DICATOR LIGHTS s03ae03
If the front passenger’ s SRS frontal airbag is activated, the passenger’ s frontal airbag ON indicator light will illuminate while the OFF indicator light will remain off.
If the front passenger’ s SRS frontal airbag is deactivated, the passenger’ s frontal airbag ON indicator light will remain off while the OFF indicator light will illuminate.
With the ignition switch turned to the“ ON” position, if both the ON and OFF indicator lights remain illuminated or off simultaneously even after the system check period, the system is malfunctioning. Contact your SUBARU dealer immediately for an inspection.
3
S _ 307540-W
: Front passenger’ s frontal airbag ON indicator light
: Front passenger’ s frontal airbag OFF indicator light
For details about the operating conditions of SRS seat cushion airbag, refer to“ SUBARU Advanced Frontal Airbag System” FP91.
The front passenger’ s frontal airbag ON and OFF indicator lights show you the status of the front passenger’ s SRS frontal airbag.
The indicator lights are located as shown in the illustration.
When the ignition switch is turned to the“ ON” position, both the ON and OFF indicator lights illuminate for 6 seconds during which time the system is checked. Following the system check, both indicator lights turn off for 2 seconds. After that, one of the indicator lights illuminates depending on the status of the front passenger’ s SRS frontal airbag determined by the SUBARU advanced frontal airbag system monitoring.
CHECK ENGINE WARNING LIGHT / MAL- FUNCTION INDICATOR LIGHT s03ae04
CAUTION
If the CHECK ENGINE warning light / malfunction indicator light illuminates while you are driving, have your vehicle checked / repaired by your SUBARU dealer as soon as possible. Continued vehicle operation without having the emission control system checked and repaired as necessary could cause serious damage, which may not be covered by your vehicle’ s warranty.
If this light illuminates steadily or blinks while the engine is running, it may indicate that there is at least one problem or potential problem somewhere in the emission control system.
If the light illuminates constantly s03ae0401
If the light illuminates constantly while driving or does not turn off after the engine starts, an emission control system malfunction has been detected.
– CONTINUED –
