520
SPECIFICATIONS
12-1. SPECIFICATIONS s12aa
These specifications are subject to change without notice.
DIMENSIONS
s12aa01
Overall length
183.3( 4,655)
Overall width
72.0( 1,830)
Overall height
68.1( 1,730)
Wheel base
105.1( 2,670)
Front
61.6( 1,565)
Models with 18 inches tires
Rear
61.8( 1,570)
Tread
Front
61.8( 1,570)
Models with 19 inches tires
Rear
62.0( 1,575)
Ground clearance *
8.7( 220)
in( mm)
*: Measured with vehicle empty
ENGINE s12aa02
Engine model FB25( 2.5 L, DOHC, non-turbo)
Engine type
Horizontally opposed, liquid cooled 4 cylinder, 4-stroke direct injection gasoline engine
Displacement cu-in( cc) 152( 2,498) Bore 6 Stroke in( mm) 3.70 6 3.54( 94.0 6 90.0) Compression ratio 12.0 Firing order 1 – 3 – 2 – 4
ELECTRIC MOTOR( Traction Motor)
Type
Permanent magnet synchronous motor
Maximum output
88 kW
Maximum torque
199 lbf · ft( 270 N · m, 27.5 kgf · m)
s12aa23
