MAINTENANCE AND SERVICE 517
. It is recommended that the battery should be replaced by a SUBARU dealer.
. Use a new battery.
. After replacing the battery, confirm that the access key fob / transmitter functions properly.
2. Wrap a flat-head screwdriver with vinyl tape or a cloth, and insert it in the gap to remove the cover.
REPLACING BATTERY OF AC- CESS KEY FOB s11bk01
Button battery: CR2032 or equivalent
CAUTION
. When removing or fitting the access key fob cover, make sure that the plastic part does not come off or become misaligned.
. Before replacing the battery, remove any static electricity.
S _ B02411-MW
3. Take out the battery using a flat-head screwdriver with vinyl tape or a cloth.
1. Take out the emergency key.
11
S _ B02412-MW
4. Insert a new battery with its positive(+) side facing upward as shown in the figure.
Release button Emergency key
S _ 204470-MW
S _ B02413-MW
– CONTINUED –
