INSTRUMENTS AND CONTROLS 201
DRIVER MONITORING SYSTEM OFF INDICATOR LIGHT( If Equipped) s03aea5
This indicator illuminates when“ Driver Monitoring System” is touched to deactivate the Driver Monitoring System. Refer to“ Driver Monitoring System OFF indicator light” FP399.
DRIVER MONITORING SYSTEM TEMPORARY STOP INDICATOR LIGHT( If Equipped) s03aea6
This indicator illuminates when the Driver Monitoring System is temporarily stopped. Refer to“ Driver Monitoring System temporary stop indicator light” FP399.
NOTE
The Driver Monitoring System stops temporarily when the temperature of the Driver Monitoring System unit is high.
HYBRID FAIL LAMP s03ae71
The hybrid fail lamp illuminates when a malfunction occurs in the hybrid system.
CAUTION
When the hybrid fail lamp is illuminated, an telltale screen will be displayed simultaneously on the combination meter. Perform the procedure shown on the combination meter, then have your vehicle inspected by a SUBARU dealer immediately.
HYBRID SYSTEM OVER- HEAT WARNING LIGHT s03aea2
This warning light illuminates when the temperature of the inverter with converter assembly is high. When this warning light illuminates, the power output limits are activated and it will only be possible to
drive the vehicle at only low speeds. If the hybrid system overheat warning light does not turn off, set the shift position to“ P” and stop the vehicle for about 5 minutes. When the warning light turns off, normal driving will again be possible. If the warning light stays on even after stopping the vehicle for more than 5 minutes, consult your SUBARU dealer to have your vehicle inspected.
PEDESTRIAN ALERT SYSTEM WARNING INDI- CATOR LIGHT s03aeb4
This light blinks when a malfunction occurs in the pedestrian alert system.
HYBRID READY INDI- CATOR LIGHT s03ae73
This light illuminates when the hybrid system has started. It turns off when the hybrid system has been turned off.
This light flashes while the hybrid system is preparing to start.
CAUTION
If the hybrid READY indicator light does not illuminate when the hybrid system has been started, have your vehicle checked at a SUBARU dealer.
EV( Electric Vehicle) IN- DICATOR s03ae99
This light illuminates in the following cases.
. When driving only using the electric motor power
. When the engine is automatically stopped by the hybrid system
– CONTINUED –
3
