INSTRUMENTS AND CONTROLS 197
SECURITY INDICATOR LIGHT s03ae16
This indicator light shows the status of the alarm system. It also indicates operation of the immobilizer system.
Alarm system s03ae1601
It blinks to show the driver the operational status of the alarm system. For detailed information, refer to“ Alarm System” FP152.
Immobilizer system s03ae1602
The security indicator light starts blinking in the following conditions.
. Immediately after the push-button ignition switch is turned to the“ OFF” position.
. Immediately after the driver’ s door is opened or closed when all of the following conditions are met.
– The push-button ignition switch is in the“ ON” or“ ACC” position.
– The hybrid system is not running.
In the event that an unauthorized key is used( for example, the key is unregistered or the ID code does not match), the power is not switched to“ ON” and the security indicator light continues blinking.
NOTE
. The security indicator light remains off in the following conditions. It means that the matching of the ID code is completed and the immobilizer system is deactivated, and it does not indicate a malfunction.
– While the hybrid system is running – The push-button ignition switch
has been turned to the“ ON” or“ ACC” position and the driver’ s door has not been opened or closed
. Even if a malfunction occurs, such as the security indicator light flashes irregularly, it will not affect the functionality of the immobilizer system.
SI-DRIVE INDICATOR
Intelligent( I) mode Sport( S) mode s03ae52
S _ 308062-W
This light indicates the current SI-DRIVE mode.
For details of SI-DRIVE mode, refer to“ SI-DRIVE” FP338.
SELECT LEVER / GEAR POSI- TION INDICATOR s03ae43
S _ 308253-W
Select lever / gear position indicator
The select lever position is displayed on the indicator.
When the manual mode is selected, the current gear position will appear on the indicator. Refer to“ Selection of Manual Mode” FP337.
3
– CONTINUED –
