86
SRS airbag ( Supplemental Restraint System airbag )
23 |
Side impact sensor ( under the rear center |
seat ) |
24 |
Side impact sensor ( front door left-hand |
side ) |
25 |
Side impact sensor ( front door right-hand |
side ) |
26 |
Lap belt pretensioner ( front passenger ’ s |
side ) |
27 |
Lap belt pretensioner ( driver ’ s side ) |
28 |
Driver ’ s seat position sensor |
29 |
Passenger ’ s seat position sensor |
30 |
Rear seatbelt pretensioner ( front passenger |
’ s side ) |
31 |
Rear seatbelt pretensioner ( driver ’ s side ) |
& SUBARU advanced frontal airbag system
S01AH02
Your vehicle is equipped with a SUBARU advanced frontal airbag system that complies with the new advanced frontal airbag requirements in the amended Federal Motor Vehicle Safety Standard ( FMVSS ) No . 208 .
The SUBARU advanced frontal airbag system automatically determines the deployment force of the driver ’ s SRS frontal airbag at the time of deployment as well as whether or not to activate the front passenger ’ s SRS frontal airbag and , if activated , the deployment force of the SRS frontal airbag at the time of deployment .
ADVANCED AIR BAGS ” and a tag attached to the glove box lid beginning with the phrase “ Even with Advanced Air Bags ”. Make sure that you carefully read the instructions on the warning labels and tag .
Always wear your seatbelt . The SUBARU advanced frontal airbag system is a supplemental restraint system and must be used in combination with a seatbelt . All occupants should wear a seatbelt or be seated in an appropriate child restraint system .
For the locations of the SRS airbags , refer to “ Components ” FP84 .
In a moderate to severe frontal collision , the following components deploy .
. SRS frontal airbag for driver . SRS frontal airbag for front passenger . SRS knee airbag for driver . SRS curtain airbag * 1 * 1 : When an offset frontal collision that is severe enough to deploy the front airbag occurs .
These components supplement the seatbelts by reducing the impact to the occupant ’ s head , chest and knees .
Your vehicle has warning labels on the driver ’ s and front passenger ’ s sun visors beginning with the phrase “ EVEN WITH
