36
Seats
System settings . Refer to “ Driver Monitoring System settings ” FP217 .
! Registration of memory position with button “ 1 ” or “ 2 ”
S01AQ060301
1 . Adjust the seat position under the following conditions . . The parking brake is applied . . The ignition switch is in the “ ON ” position . . The select lever is in the “ P ” position .
2 . Register the adjusted positions by either of the following procedures . . Press the “ SET ” button , then press either “ 1 ” or “ 2 ” until a chirp sounds within 5 seconds .
. While pressing and holding the “ SET ” button , press either “ 1 ” or “ 2 ” until a chirp sounds within 5 seconds .
A chirp will sound once , and the seat position and outside mirror angle on the passenger ’ s side will be registered .
NOTE
If a new position is registered for the same button , the previously registered memory position is deleted .
! Registration of the reverse tiltdown mirror angle with button “ 1 ” or “ 2 ”
S01AQ060306
CAUTION
Depress the brake pedal when registering the reverse tilt-down mirror angle .
1 . Move the select lever to the “ R ” position , then the outside mirror angle will move to the reverse tilt-down position .
2 . Adjust the outside mirror angle . For details about the settings , refer to “ Remote control mirror switch ” FP252 .
3 . Move the select lever to the “ P ” position , then the outside mirror angle will return to its original position .
4 . Register the adjusted positions by either of the following procedures .
. Press the “ SET ” button , then press either “ 1 ” or “ 2 ” until a chirp sounds within 5 seconds .
. While pressing and holding the “ SET ” button , press either “ 1 ” or “ 2 ” until a chirp sounds within 5 seconds .
A chirp will sound once , and the seat position and outside mirror angle will be registered .
NOTE
The factory setting ( default setting ) for this function is set as the front passenger ’ s side mirror . The setting of the right and left side mirror / front passenger ’ s side mirror operation can be changed by a SUBARU dealer . Contact your SUBARU dealer for details .
! Registration of memory position with a key fob
S01AQ060302
1 . Adjust the seat position under the following conditions . . The parking brake is applied . . The ignition switch is in the “ LOCK ”/
“ OFF ” position . . The select lever is in the “ P ” position .
