BSD / RCTA 365
|
inspected at a SUBARU dealer .
! System temporary stop due to reduced radar sensitivity
S07BM0802
|
|
|
|
& BSD / RCTA warning light
! System malfunction
S07BM04
|
|
S07BM0403 |
|
|
& BSD / RCTA OFF switch |
S07BM05 |
|
|
BSD / RCTA OFF switch |
|
1 BSD / RCTA temporary stop message due to reduced radar sensitivity
2 BSD / RCTA OFF indicator light
This display appears when the detectability of the radar sensors is reduced . Once the condition is corrected , the system will recover from the temporary stop condition and the indicator will disappear . If the indicator remains displayed for a prolonged time , have the system inspected at a SUBARU dealer .
1 BSD / RCTA malfunction message 2 At first , this message will appear 3 Then this message will appear 4 BSD / RCTA warning light
This display appears when a malfunction occurs in the system . Contact a SUBARU dealer and have the system inspected .
Starting and operating
BSD / RCTA OFF indicator light
If the BSD / RCTA OFF switch is pressed , the BSD / RCTA OFF indicator light appears on the combination meter , and the
– CONTINUED –
