Braking 333 |
|||||||||
|
NOTE
When the following operations are performed , an operating sound from the electronic brake boost control module may be heard . This is not a malfunction .
. The brake pedal was operated . . The driver ’ s door was opened . . The EyeSight function was activated .
. Several minutes have passed after the engine stopped .
! Supplemental booster function when electronic brake booster fails
S07AK020701
If there is a malfunction in the braking system , the power for the braking will be stored by controlling the hydraulic pressure of the VDC system .
When the brake pedal is depressed while the supplemental booster function is operating , an operation sound and brake pedal vibration may be generated .
! Electronic brake booster warning
S07AK020702
The brake system warning light illuminates when the electronic brake booster is malfunctioning . In addition , the warning messages “ Brake System ” and “ Check Owner ’ s Manual ” are displayed alternately on the combination meter display ( color
|
LCD ). If the warning light illuminates , promptly park in a safe location as soon as possible and contact your SUBARU dealer . Refer to “ Electronic brake booster warning ” FP178 .
! Brake assist system
WARNING
S07AK0203
Do not be overconfident about the brake assist . It is not a system that brings more braking ability to the vehicle beyond its braking capability . Always use the utmost care when driving regarding vehicle speed and safe distance .
|
CAUTION
When you need to brake suddenly , continue depressing the brake pedal strongly to bring the effect of the brake assist .
|
Brake assist is a driver assistance system . It assists the brake power when the driver cannot depress the brake pedal strongly and the brake power is insufficient .
Brake assist generates the brake power according to the speed at which the driver depresses the brake pedal .
|
NOTE
When you depress the brake pedal strongly or suddenly , the following will occur . However , even though these occur , they do not indicate any malfunctions , and the brake assist system is operating properly .
. You might feel that the brake pedal is applied by lighter force and generates a greater braking force .
. You might hear an ABS operating noise from the engine compartment .
& Disc brake pad wear warning indicators
S07AK03
The disc brake pad wear warning indicators on the disc brakes give a warning noise when the brake pads are worn .
|
Starting and operating |
||||
– CONTINUED – |
