State emission testing ( U . S . only ) 307 |
||||||||
|
engine performance .
! If the fuel filler lid cannot be opened
S07AA0203
If the fuel filler lid cannot be opened due to malfunction or a dead battery , it can be opened from the cargo area .
1 . Remove the access cover at the rightside of the cargo area trim using flathead screwdriver .
|
1 Clip
2 . Remove the orange knob from the clip .
3 . Pull the orange knob to unlock the fuel filler lid .
|
7-2 . State emission testing ( U . S . only )
WARNING
S07AB
Only use a four-wheel dynamometer when testing an All-Wheel Drive model .
Testing of an AWD model must NEVER be performed on a single two-wheel dynamometer . Attempting to do so will result in uncontrolled vehicle movement and may cause an accident or injuries to persons nearby .
|
CAUTION
. At state inspection time , remember to tell your inspection or service station in advance not to place your SUBARU AWD vehicle on a two-wheel dynamometer . Otherwise , serious transmission damage will result .
. Resultant vehicle damage due to improper testing is not covered under the SUBARU Limited Warranty and is the responsibility of the state inspection program or
|
