Air filtration system 273 |
|||||||
|
& Replacing the cabin air filter
S04AE01
1 . Remove the glove box .
NOTE
We recommend that you take measures to protect the center console with masking tape first , so that you avoid scratching the center console with the glove box .
( 1 ) Open the glove box .
( 2 ) Remove the damper shaft from the glove box .
|
1 Stoppers
( 3 ) Push in the stoppers located on both sides of the glove box and then pull down the glove box as far as it will go .
|
and remove the hinge portion . When doing this , be careful not to damage the hinge . |
2 . Remove the cabin air filter according to the following procedure in order to prevent dust on the cabin air filter from falling to the inside of its housing . ( 1 ) Push in the four stoppers to unlock , and then slowly pull out the cabin air filter 0.4 in ( 1 cm ) from the housing .
( 2 ) Completely pull out the cabin air filter by gently tilting the front side of the cabin air filter downward .
|
Climate control |
|||
( 4 ) Pull out the glove box horizontally |
|||||||
– CONTINUED – |
