Defrosting 271 |
4-5 . Defrosting |
|
|
|
S04AH |
. For types B and C climate control system , after defrosting the windshield by pressing the defroster button “ ”, pressing the button again returns the system to the setting that had been selected before the defroster was activated . |
4-6 . Operating tips for heater and air conditioner
S04AD
& Cleaning ventilation grille
S04AD01
|
1 If equipped
Select the “ ” or “ ” mode to defrost or dehumidify the windshield and front door windows .
NOTE
. When the “ ” or “ ” mode is selected , the air conditioner operates automatically regardless of the position of the air conditioner button to defrost the windshield more quickly . However the indicator on the air conditioner button may not illuminate . At the same time , the air inlet selection is automatically set to the outside air mode .
1 Front ventilation inlet grille
Always keep the front ventilation inlet grille free of snow , leaves , or other obstructions to ensure efficient heating and defrosting . Since the condenser is located in front of the radiator , this area should be kept clean because cooling performance is impaired by any accumulation of insects and leaves on the condenser .
Climate control
– CONTINUED –
