1 If equipped
Defrost for type A : Windshield defroster outlets and both side outlets of the instrument panel ( Refer to “ Defrosting ” FP271 .)
|
& MAX A / C mode ( for type B and C )
S04AJ06
For quicker cooling , press the MAX A / C button .
When the MAX A / C mode is on , the following settings will be changed automatically .
. The air conditioner will turn on .
. The temperature will be set on the lowest .
. The fan speed will be set on the maximum speed .
. The air inlet will be set to recirculation .
. The airflow mode setting will be set to ventilation mode .
To turn off MAX A / C mode and return the previous setting , press the MAX A / C button again .
& Temperature control
S04AJ02
Turn the temperature control dial to set the preferred interior temperature .
For models with the Driver Monitoring System , the temperature setting can also be changed with the gesture control function . Refer to “ Gesture control ” FP391 .
|
NOTE
The controllable temperature range may vary depending on the regional specifications of the vehicle .
! SYNC mode ( type B )
S04AJ0207
When the SYNC mode is turned on , both the driver ’ s and passenger ’ s side temperatures are synchronized using the driver ’ s side temperature control dial .
Press the SYNC button to turn on the SYNC mode . The SYNC button indicator will illuminate .
Press the SYNC button again or turn the passenger ’ s side temperature control dial to cancel the SYNC mode . The SYNC button indicator will not illuminate . In this case , temperature control on the driver ’ s side and passenger ’ s side is separated . The temperature will be controlled individually using the driver ’ s and passenger ’ s temperature control dials .
& Fan speed control
S04AJ03
Select the preferred fan speed by turning the fan speed control dial .
& Air conditioner control
S04AJ04
The air conditioner operates only when the engine is running .
Press the air conditioner button while the
|
Climate control |
– CONTINUED – |
