Mirrors 253 |
|||||
|
verse ) position .
3 . The outside mirror angle moves downward .
The outside mirror angle will return to its original position when the following condition are met .
. After approximately 9 seconds from the select lever is moved to any position other than R ( Reverse ).
. The ignition switch is turned to the “ OFF ” position .
. The vehicle is running .
NOTE
. The reverse tilt-down mirror angle can be registered with button “ 1 ”, “ 2 ” or each of the key fobs . For details , refer to “ Memory function ( driver ’ s seat – if equipped )” FP35 .
. The reverse tilt-down mirror angle can also be retrieved with the Driver Monitoring System user information . To do so , perform user registration in the Driver Monitoring System settings . Refer to “ Driver Monitoring System settings ” FP217 .
. The operational / non-operational setting can be changed by operating the combination meter display ( color LCD ). For details , refer to “ Vehicle Setting ” FP199 .
|
. The factory setting ( default setting ) for this function is set as the front passenger ’ s side mirror . The setting of the right and left side mirror / front passenger ’ s side mirror operation can be changed by a SUBARU dealer . Contact your SUBARU dealer for details .
CAUTION
Depress the brake pedal during the reverse tilt-down mirror angle adjustment .
To adjust the reverse tilt-down mirror angle , adjust the outside mirror using the remote control mirror switch while the reverse tilt-down operates . For details about how to adjust the outside mirror angle , refer to “ Remote control mirror switch ” FP252 .
Memory function :
The angle of the reverse tilt-down mirror can be registered . Register the position with button “ 1 ”, “ 2 ” or each of the access key fobs and retrieve the position .
For details about registration or retrieval of a position , refer to “ Memory function ( driver ’ s seat – if equipped )” FP35 .
|
NOTE
If the seat is moved forward or backward 1.18 in ( 30 mm ) or more , the reverse tilt-down will move to the factory default position or the last position hold .
Hold last position function :
The angle of the reverse tilt-down mirror can be set to the latest adjusted angle .
The hold last position function operates when the following condition are met .
. The memory function is not used .
. The seat is moved forward or backward 1.18 in ( 30 mm ) or more .
NOTE
. The factory setting ( default setting ) for this function is set as “ nonoperational ”. This setting can be changed to “ operational ” at SUBARU dealers . For more details , contact a SUBARU dealer .
. If the hold last position function setting is “ non-operation ”, the reverse tilt-down will move to the factory default position .
|
Instruments and controls |
