Multi-function display ( color LCD ) 223 |
||||||||
|
! Display / Beep settings
S03BP2805
You can set the display settings and volume settings .
! Screen OFF setting
S03BP280501
1 . Select “ Screen Off ” from the 2nd menu in setting screen . Refer to “ Setting screen ” FP214 .
|
NOTE
While the screen is off , the screen switches to the climate control screen only when the climate control system is operated .
! Favorite setting
S03BP280502
1 . Select “ Favorite ” from the 2nd menu in setting screen . Refer to “ Setting screen ” FP214 .
|
NOTE
. You can display a maximum of the 3 items .
. The same item cannot be selected for the left , center or right location .
. Weather information for 3 hours later or 6 hours later can be displayed .
! Bypass screen setting
S03BP280503
1 . Select “ Bypass Screen ” from the 2nd menu in the setting screen . Refer to “ Setting screen ” FP214 .
|
Instruments and controls |
|||||
|
2 . Select “ Yes ” to turn off the screen . Select “ No ” to return to the previous screen .
Restoring the screen
When the INFO button is operated after the ignition switch is turned to the “ ON ” or “ ACC ” position , the screen will be restored . The screen will be restored with the basic screen that was displayed when the screen was turned off .
|
2 . Set the desired items by using the control switches . For details about items , refer to “ Favorite screen ” FP211 .
3 . Select “ Set ” to exit settings . Select “ Go Back ” to return to the previous screen without applying the setting changes .
|
2 . Select “ On ” or “ Off ” to turn the display of items on or off by using the control switches .
3 . Select “ Set ” to exit settings . Select “ Go Back ” to return to the previous screen
|
||||||
– CONTINUED – |
