210
Multi-function display ( color LCD )
! Electric components operation screen ( if equipped )
S03BP101901
3 . Pull the “ / SET ” switch to enter the selected item .
NOTE
. Indicators do not display for functions that are not equipped to the vehicle .
. The indicators of functions that are not operating are displayed in gray .
1 BSD / RCTA *
2 Reverse Automatic Braking ( RAB ) system *
3 Lane Departure Warning indicator 4 Pre-Collision Braking System indicator * 5 High beam assist 6 Front view monitor * 7 Driver Monitoring System * *: If equipped
This screen displays the electric components operation status of the vehicle .
1 . Press and hold the “ INFO ” button to enter the menu screen .
2 . Operate the “ ” or “ ” button to select the preferred item .
! Prevention safety screen
S03BP101902
1 Telltale screen 2 Steering angle 3 Vehicle posture 4 Running condition
X-MODE screen 1 Vehicle posture 2 X-MODE
This screen displays the driving status of the vehicle and the operation status functions . For functions that are operating , the indicator will illuminate or flash .
NOTE
. The vehicle posture indication may differ from the actual vehicle posture .
. When X-MODE has turned on , the screen of the multi-function display is switched to the prevention safety screen .
. The vehicle posture angle varies not only due to the angle of the road surface , but also due to the vehicle
