Warning and indicator 191 |
|
will not be automatically restarted , even if you release the brake pedal . Use normal operation to restart the engine .
! Auto Start Stop OFF indicator light ( yellow )
S03AE6502
This light will illuminate in yellow when the Auto Start Stop OFF switch is pressed to prevent the Auto Start Stop system from operating . It will turn off when the Auto Start Stop OFF switch is pressed once more to enable operation of the Auto Start Stop system .
|
& X-MODE indicator light ( if equipped )
S03AE68
|
||||||||||
|
& Auto Start Stop indicator light ( green )
S03AE66
This indicator light illuminates when the engine has been temporarily stopped by the Auto Start Stop system . It will turn off when the engine is restarted .
|
& Auto Start Stop No Activity Detected indicator light
S03AEA3
When a vehicle is stopped , the indicator light illuminates when the operating condition of the Auto Start Stop system are not met . The light will turn off when the vehicle starts driving . Refer to “ Non-operational conditions ” FP353 .
|
X-MODE indicator ( models with 1 mode ) |
X-MODE indicator ( models with 2 modes ) 1 X-MODE indicator or D . SNOW / MUD mode indicator
2 SNOW / DIRT mode indicator
This indicator appears while X-MODE is activated . It will disappear when X-MODE is deactivated . Refer to “ To activate / deactivate X-MODE ” FP341 .
& Hill descent control indicator light ( if equipped )
S03AE69
This indicator appears while the hill descent control function is in standby . It will flash while the hill descent control function is operating . It will disappear when the hill descent control function is not available . Refer to “ Hill descent control function ” FP343 .
|
Instruments and controls |
|||||||
– CONTINUED – |
