Warning and indicator 189 |
||||||||||
|
& SI-DRIVE indicator light
SI-DRIVE indicator light 1 Sport ( S ) mode ( if equipped ) 2 Intelligent ( I ) mode 3 Sport Sharp ( S #) mode ( if equipped )
S03AE52
|
This light indicates the current SI-DRIVE mode .
For details of SI-DRIVE mode , refer to “ SI-DRIVE ” FP329 .
|
& Select lever / gear position indicator
S03AE43
|
1 Upshift indicator 2 Downshift indicator 3 Select lever / gear position indicator
This indicator shows the position of the select lever .
For models with manual mode , when the manual mode is selected , the gear position indicator ( which shows the current gear selection ) and the upshift / downshift indicator light up . Refer to “ Continuously variable transmission ” FP323 .
|
& Turn signal indicator lights
S03AE20
These lights show the operation of the turn signal or lane change signal .
If the indicator lights do not blink or blink rapidly , the turn signal bulb may be burned out . Replace the bulb as soon as possible . Refer to “ Replacing bulbs ” FP489 .
& High beam indicator light
S03AE21
This light shows that the headlights are in the high beam mode .
This indicator light also illuminates when the headlight flasher is operated .
|
& High beam assist indicator light
S03AE83
This light illuminates when the high beam assist function is activated . For details about the high beam assist function , refer to “ High beam assist function ” FP234 .
|
