182
Warning and indicator
inoperative , the Vehicle Dynamics Control system becomes unable to provide ABS control . As a result , the Vehicle Dynamics Control system also becomes inoperative , causing the warning light to illuminate . Although both the Vehicle Dynamics Control system and ABS are inoperative in this case , the ordinary functions of the brake system are still available . You will be safe while driving with this condition , but drive carefully and have your vehicle checked at a SUBARU dealer as soon as possible .
NOTE
. If the electrical circuit of the Vehicle Dynamics Control system itself malfunctions , the warning light only illuminates . At this time , the ABS ( Anti-lock Brake System ) remains fully operational .
. The warning light illuminates when the electronic control system of the ABS / Vehicle Dynamics Control system malfunctions .
. The Vehicle Dynamics Control warning light , ABS warning light , and brake system warning light illuminate simultaneously if the EBD system malfunctions . For further details of the EBD system malfunction warning , refer to “ Electronic Brake Force Distribution ( EBD ) system warning ” FP178 .
The Vehicle Dynamics Control system is probably inoperative under any of the following conditions . Have your vehicle checked at a SUBARU dealer immediately .
. The warning light does not illuminate when the ignition switch is turned to the “ ON ” position .
. The warning light illuminates while the vehicle is running .
NOTE
If the warning light behavior is as described in the following examples , the Vehicle Dynamics Control system may be considered normal .
. The warning light illuminates when the ignition switch is turned to the “ ON ” position and turns off approximately 2 seconds after the engine has started .
. The warning light illuminates right after the engine is started but turns off immediately , remaining off .
. The warning light illuminates after the engine has started and turns off while the vehicle is subsequently being driven .
. The warning light illuminates during driving , but it turns off immediately and remains off .
. The warning light illuminates when the engine has stalled and continues to illuminate after the engine has been restarted . However , it will turn off once the vehicle starts moving .
! Vehicle Dynamics Control operation indicator light
S03AE1402
The indicator light flashes during activation of the skid suppression function and during activation of the traction control function .
NOTE
. The light may remain illuminated for a short period of time after the engine has been started , especially in cold weather . This does not indicate the existence of a problem . The light should turn off as soon as the engine has warmed up .
. The indicator light illuminates when the engine has developed a problem and the CHECK ENGINE warning light / malfunction indicator light is on .
The Vehicle Dynamics Control system is probably malfunctioning under the following condition . Have your vehicle checked at a SUBARU dealer as soon as possible .
