Warning and indicator 177 |
|||||||||||
checking tire pressure . The tire pressure should be checked periodically ( at least monthly ) using a tire gauge . After any change to tire pressure ( s ), the tire pressure monitoring system will not re-check tire inflation pressures until the vehicle is first driven more than 20 mph ( 32 km / h ). After adjusting the tire pressures , increase the vehicle speed to at least 20 mph ( 32 km / h ) to start the TPMS re-checking of the tire inflation pressures . If the tire pressures are now above the severe low pressure threshold , the low tire pressure warning light should turn off a few minutes later . Therefore , be sure to install the specified size for the front and rear tires . |
& ABS warning light
CAUTION
|
S03AE09
. If any of the following conditions occur , we recommend that you have the ABS repaired at the first available opportunity by your SUBARU dealer .
– The warning light does not illuminate when the ignition
|
switch is turned to the “ ON ” position .
– The warning light illuminates when the ignition switch is turned to the “ ON ” position , but it does not turn off even after the vehicle is started .
– The warning light illuminates during driving .
. When the warning light is on ( and the brake system warning light is off ), the ABS function shuts down . However , the conventional brake system continues to operate normally .
The ABS warning light , Vehicle Dynamics Control warning light , and brake system warning light illuminate simultaneously if the EBD system malfunctions . For further details of the EBD system malfunction warning , refer to “ Electronic Brake Force Distribution ( EBD ) system warning ” FP178 .
NOTE
If the warning light behavior is as described in the following conditions , the ABS may be considered normal .
. The warning light illuminates when the ignition switch is turned to the “ ON ” position and turns off approximately
|
2 seconds after the engine has started .
. The warning light illuminates right after the engine is started but turns off immediately , remaining off .
. The warning light remains illuminated after the engine has been started , but it turns off while driving .
. The warning light illuminates during driving , but it turns off immediately and remains off .
When driving with an insufficient battery voltage , such as when the engine is jump started , the ABS warning light may illuminate . This is due to the low battery voltage and does not indicate a malfunction . When the battery becomes fully charged , the light will turn off .
|
& Brake system warning light ( red )
WARNING
|
S03AE10
. Driving with the brake system warning light on is dangerous . This indicates your brake system may not be working properly . If the light remains illuminated , have the brakes inspected by a SUBARU dealer immediately .
|
Instruments and controls |
||||
– CONTINUED – |
