Warning and indicator 169 |
||||
|
Front passenger ’ s seat
! Operation
S03AE011401
When the ignition switch is turned to the “ ON ” position , the driver ’ s and / or front passenger ’ s warning light will illuminate , then it will blink for several seconds . If the seatbelt of the driver ’ s seat is not fastened , the warning chime may make a peep sound .
NOTE
. If the driver ’ s and / or front passenger ’ s seatbelt ( s ) are / is not fastened while driving , the seatbelt warning system operates as follows according to the vehicle speed . – The warning light will illuminate when driving approximately 4 mph ( 6 km / h ) or less .
|
– The warning light will blink , and the warning chime will make a peep sound when driving between approximately 4 mph ( 6 km / h ) and 13 mph ( 20 km / h ). The warning chime will stop when the vehicle stops .
– The warning light will blink , and the warning chime will sound loudly when 15 seconds have elapsed while driving between approximately 4 mph ( 6 km / h ) and 13 mph ( 20 km / h ).
– The warning light will blink , and the warning chime will sound loudly when driving approximately more than 13 mph ( 20 km / h ).
. The warning light will turn off and the warning chime will stop when the seatbelt is fastened .
If there is no passenger on the front passenger ’ s seat , the seatbelt warning system for the front passenger ’ s seat will be deactivated . The front passenger ’ s seatbelt warning system monitors whether or not there is a passenger on the front passenger ’ s seat .
|
CAUTION
Observe the following precautions . Failure to do so may prevent the device from functioning correctly or cause the device to fail .
. Do not install any accessory such as a table or TV onto the seatback .
. Do not store a heavy load in the seatback pocket .
. Do not allow the rear seat occupant to place his / her hands or legs on the front passenger ’ s seatback , or allow him / her to pull the seatback .
. Do not use front seats with their backward-forward position and seatback not being locked into place securely . If any of them are not locked securely , adjust them again . For adjusting procedure , refer to “ Manual seat ” FP33 .
If the seatbelt warning system for the front passenger ’ s seat does not function correctly ( e . g ., it is activated even when the front passenger ’ s seat is empty or it is deactivated even when the front passenger has not fastened his / her seatbelt ), take the following actions .
|
– CONTINUED – |
Instruments and controls |
