Child restraint systems 73 |
|||||||||||||
|
! Tether anchorages
S01AG070102
|
The tether anchorages ( upper anchorages ) are provided at the locations shown in the above illustration . For details , refer to “ Top tether anchorages ” FP75 .
! To install a child restraint system using lower and tether anchorages
S01AG070103
WARNING
Before installing a child restraint system , be sure to confirm that the seatback is securely locked into place . Otherwise , in an accident , serious injury or death could result .
|
1 . Move the seatback back and forth to confirm that it is securely locked into place . – Check the red colored unlocking marker which is attached to the bottom of the lock release knob is not visible . For details , refer to “ Folding down the rear seatback ” FP40 . |
2 . You will find “ ” marks at the bottoms of the rear seatback . These marks indicate the positions of the lower anchorages ( bars ). |
3 . Peel off the anchorage cover from the selected side of the rear seatback . Fold the peeled anchorage cover in half and affix it with hook and loop tape to expose the anchorages ( bars ) to be used for installation of the child restraint system . |
Seat , seatbelt and SRS airbags |
||||||||
– CONTINUED – |
