Specifications 499
& Temporary spare tires
S12AA15
Temporary spare tire size Temporary spare tire inflation pressure ( recommended cold tire inflation pressure )
T145 / 80 D17 60 psi ( 420 kPa , 4.2 kgf / cm 2 )
& Brake pedal
S12AA27
Pedal clearance |
2.56 ( 65 )* |
Pedal free play |
0.02 - 0.11 ( 0.5 - 2.7 ) |
in ( mm )
*: Minimum value when pedal is operated with a force of 110 lbf ( 490 N , 50 kgf )
& Brake disc
S12AA18
If you need information on the usage limit value of brake discs and the method for measuring them , we recommend that you consult your SUBARU dealer .
& Brake pad
S12AA28
Brake pad wear limit 0.06 ( 1.5 ) in ( mm )
Specifications
