488
Replacing bulbs
5 . Route the wire as shown in the illustration .
& Door step light CAUTION
S11BE10
Replacing the bulb could cause a short circuit . Have the bulb replaced by your SUBARU dealer .
& Other bulbs
S11BE29
It may be difficult to replace the bulbs . Have the bulbs replaced by your SUBARU dealer if necessary .
& Adjusting headlight aim
S11BE57
& Cargo area light
S11BE21
6 . Install the light cover on the rear gate .
& Vanity mirror light CAUTION
S11BE34
Replacing the bulb could cause burns since the bulb may be very hot . Have the bulb replaced by your SUBARU dealer .
Cargo area light ( models without rear gate light )
1 . Remove the lens by prying the edge of the lens with a flat-head screwdriver .
2 . Pull the bulb out of the socket . 3 . Install a new bulb . 4 . Put the lens back in place .
1 Adjustment screw A 2 Adjustment screw B 3 Adjustment direction mark
! Before checking the headlight aiming
S11BE5701
1 . Make sure the vehicle has a full tank of gasoline and the area around the headlight is not deformed .
2 . Park the vehicle on level ground . 3 . Sit in the driver ’ s seat . 4 . Bounce the vehicle several times .
