470
Tires and wheels
& Wear indicators |
|
|
|
S11AV06 |
is worn beyond the acceptable limit and must be replaced immediately . With a tire in this condition , driving at high speeds in wet weather can cause the vehicle to hydroplane . The resulting loss of vehicle control can lead to an accident . |
& Rotational direction of tires
S11AV11
|
1 New tread 2 Worn tread 3 Tread wear indicator
Each tire incorporates a tread wear indicator , which becomes visible when the depth of the tread grooves decreases to 0.063 in ( 1.6 mm ). A tire must be replaced when the tread wear indicator appears as a solid band across the tread .
WARNING
When a tire ’ s tread wear indicator becomes visible , the tire
NOTE
For safety , inspect tire tread regularly and replace the tires before their tread wear indicators become visible .
Example of rotational direction marked on the sidewall
1 Front
If the tires have specific rotational direction , refer to the arrow marked on the side wall .
The arrow should be pointing forward direction when the wheels are fitted .
