356
BSD / RCTA
! Rear Cross Traffic Alert ( RCTA )
S07BM0103
! Limitations of the detectability of RCTA
S07BM010301
Since the detectability of RCTA is limited , the RCTA may not operate properly in angled parking .
vehicle .
1 Operating range
The system notifies the driver of another vehicle approaching from either side when driving in reverse . This feature helps the driver check the rear and side areas of the vehicle when moving backward .
If the system detects a vehicle approaching from either side while moving backward , it warns the driver of dangers in the following way .
. The BSD / RCTA approach indicator light ( s ) on the outside mirror ( s ) flashes .
. A warning buzzer sounds .
. An icon appears on the rear view camera screen ( audio / navigation monitor )
Example 1 1 The detection range of the radar sensors 2 Area out of detection range of the radar sensors
A Vehicle that may not be detected . B Parked vehicle
WARNING
An approaching vehicle ( A ) may not be detected because the detection range is limited by the parked vehicle ( B ). Always be sure to check the surroundings when reversing the
Example 2 1 The detection range of the radar sensors C Vehicle that may be detected .
NOTE
The system may detect that a vehicle ( C ) is passing in front of your vehicle . Always be sure to check the surroundings when reversing the vehicle .
