294
Front View Monitor
& Guiding line
1 Guiding line 2 Warning message
S06BA04
The guiding line that indicates the width and the front end of your vehicle is displayed on the display .
& Handling of camera
CAUTION
S06BA05
Observe the following instructions . Otherwise , the system may malfunction .
. Do not apply any strong impact to the camera such as banging it or hitting it with an object . The mounting angle may change .
. The camera unit is a waterproof structure . Do not attempt to remove , disassemble or modify the unit .
. Do not rub strongly or polish the camera lens with a hard brush or abrasive compounds . The lens may be scratched resulting in an adverse effect to the camera image .
. The camera lens is made of glass or plastic . Do not allow any organic solvent , body wax , oil film remover or glass coating agent to become attached on the lens surface . If any becomes attached , remove it immediately .
. Do not expose the camera lens to any sudden temperature change , for example , spraying hot water on it in cold weather .
. Do not apply the water jet of a high pressure washer to the camera or the surrounding area when cleaning the vehicle . The impact by the strong water pressure may cause the camera to come off . Also , water may enter inside the camera and cause a malfunction .
. If the camera is exposed to any impact , it may lead to malfunction of the camera . Have the camera inspected by your SUBARU dealer as soon as possible .
. Do not use a steam cleaner under any circumstances . Some types of steam cleaners inject hot steam .
. The camera surface may be damaged by a flying stone .
NOTE
If the camera lens is contaminated , no sharp image is available . When the camera is contaminated with water drops , snow or mud , wash it with water and wipe away any moisture with a soft cloth . If it heavily gets dirty , wash it with a neutral detergent .
